A tile-insert drain replaces the metal grate with a tray that accepts the same tile or stone as the surrounding floor. The result is a drain that visually disappears into the floor pattern.
How It Works
The drain has a recessed frame with an adjustable insert tray. The installer cuts a piece of floor tile or stone to fit the tray and sets it in place, slightly raised on small feet or spacers so water can still flow into the channel around its edges.
Specification
| Specification | Options |
|---|---|
| Format | Linear (200–1200 mm, custom) and square inserts |
| Tile thickness | Adjustment range matched to the specified tile or stone |
| Frame finish | Brushed / polished / matte PVD — visible edge detail |
| Body height | Low-profile and standard |
| Material | Stainless steel 201 / 304 (brass available as a custom option) |
| Finish | Brushed / polished / matte PVD |
| Outlet | Horizontal, vertical, side |
| Access | Insert lifts out for cleaning |
What to Check Before Specifying
| Item | Why it matters |
|---|---|
| Tile thickness | The frame adjustment range must accept the tile |
| Cutting tolerance | The insert needs accurate cutting — allow a small gap at the edges |
| Tile type | Porcelain, ceramic and stone work; vinyl and LVT generally do not |
| Cleaning access | The insert must lift out easily for hair removal |
| Slip resistance | The insert has the same surface as the floor — check the rating suits a wet area |
Advantages and Limitations
Advantages: visually continuous floor; no metal contrast; ideal where a grille would break the pattern.
Limitations: requires precise on-site cutting; flow rate is generally lower than an open grate because water enters around the insert edges; the insert must be lifted for cleaning.
Frequently Asked Questions
Send us your tile type and thickness and we will confirm the frame and insert specification. Request a Quote
