Step-by-step installation documentation for AERLO shower drains and floor drains, covering drain setting, waterproofing, screed and tiling.
What the Guides Cover
- Setting out and confirming the outlet route
- Building the support and packer
- Positioning the drain body to the finished tile line
- Waterproofing over the sealing flange and up the wall
- Screed and single-plane fall to the channel
- Tiling around the frame and protecting the grate
- Water testing before handover
General Installation Requirements
| Item | Requirement |
|---|---|
| Support | Solid, non-moving base — packer or noggin frame on timber |
| Level reference | Finished tile line, not the screed |
| Waterproofing | Membrane continuous over flange and up wall |
| Fall | Single plane to the drain channel, minimum fall per tile format |
| Testing | Water test before handover |
Request a Guide
Tell us the model or product type and we will send the matching installation document. Contact us
