Dimensioned drawings and installation details for AERLO drainage products, for architects, M&E contractors and specifiers.
Drawing Types
| Drawing | Use |
|---|---|
| Dimensioned product drawings | Overall length, width, height, outlet position |
| Installation details | Section through drain, support, waterproofing, screed and tile |
| Outlet configuration drawings | Horizontal, vertical and side outlet routing options |
| Frame adjustment details | Height adjustment ranges against tile thickness |
For Design-Stage Support
If you are detailing a project and need to confirm that the drain will work with the floor build-up, tile thickness and outlet route, send us:
- The floor section or build-up (slab to finished tile)
- Tile or stone thickness
- Shower opening width and drain position
- Outlet direction and available pipe route
We will confirm the correct drain and provide the matching drawing. Contact us
