800 mm wall-position linear drain in brushed stainless steel, with integrated waterproofing flange and tool-free hair trap access. Single-plane fall, large-format tile compatible, available in 201 or 304 grade.
| Specification | Detail |
|---|---|
| Length | 800 mm |
| Body height | 50 mm |
| Material | Stainless steel 201 / 304 (brass available as a custom option) |
| Finish | Brushed stainless steel |
| Grate type | Slotted steel grate / tile-insert option |
| Outlet | Horizontal |
| Waterproofing | Integrated sealing flange |
| Maintenance | Tool-free grate removal, accessible hair trap |
| Installation | Wall position, single-plane fall |
Key Features
- Integrated waterproofing flange — the membrane bonds directly to the drain body, which is the single most important detail in preventing leaks
- Height-adjustable frame — corrects on-site tile thickness variance so the grate sits flush, not proud or recessed
- Tool-free grate removal — hair trap accessible in seconds, without tools or levering against the tile edge
- Rigid construction — resists deflection under load, so tile edges around the frame do not crack
- Single-plane fall — lets large-format tile run to a straight wall line instead of being cut to four falls
Dimensions and Installation
| Dimension | Value |
|---|---|
| Overall length | 800 mm |
| Channel width | 70 mm (nominal) |
| Body height | 50 mm |
| Minimum floor build-up | Confirm against your floor section — see below |
| Outlet diameter | Confirm against the waste pipe on site |
Before ordering: measure the available floor build-up at the drain position (slab to finished tile surface) and confirm the outlet direction and pipe size. Send us these figures and we will confirm the drain suits your floor section — see minimum installation depth.
Certification and Documentation
Documentation available on request for this product:
- Material certificate confirming stainless steel grade
- Flow rate test data
- Dimensioned drawings
- Installation instructions
Tell us your destination market and project requirements and we will confirm which documentation applies. See certificates and test reports.
Where This Drain Is Used
| Application | Why this model suits it |
|---|---|
| Bathroom renovation | Adjustable frame corrects existing floor levels |
| Thin floors | 50 mm body fits where standard bodies do not |
| Wooden subfloors | Horizontal outlet routes between joists |
| Accessible bathrooms | Flush grate, single-plane shallow fall |
| Hotel projects | Standardised specification, tool-free cleaning |
Related Questions
- What is the minimum installation depth?
- How much slope is required?
- How to waterproof around the drain?
- How to clean a linear drain?
Options and Variants
| Option | Available |
|---|---|
| Length | Made to order from 200 mm to 1200 mm |
| Material grade | 201 / 304 stainless steel |
| Finish | Brushed / polished / matte PVD |
| Grate | Slotted steel / tile-insert |
| Outlet | Horizontal / vertical / side |
| Branding | Private label available on request |
Packaging and Delivery
- Protective film on visible surfaces, drain body and grate packed separately
- Export-grade cartons with product and quantity marking
- Pallets strapped with corner protection
- EXW / FOB / CFR / CIF / DDP — quoted against your destination
See packaging and shipping for the full standard.
Request a Quote
Send us: quantity, outlet configuration, material grade, finish and destination. We will come back with pricing, lead time and delivery terms.
